CRANE">
SERVICE
REPORT
Company Reg No : 198602637N
JOBNO : 20120117
ISO 9001:2008 accredited
Page 1 of 4
PORT:LISNAVE
VESSEL:
DATE:15/03/2012
PORTUGAL
MAKE:BLM
EQUIPMENT:
,
PROVISION CRANE
MODEL:BRISSONNEAU
DEFECTS/REASON FOR CALL :
SERVICE AND LOAD TEST.
ITEM
DESCRIPTION
REMARKS
FUNCTION TEST:-
Both port and stbd
hose crane function
tested found port hose
crane working
satisfactory except
1
some leakage slewing
hyd motor counter
balance valve.
Stbd hose crane found
luffing down unable to
operate and leakage
from hoist motor.
TROUBLESHOOT STBD HOSE
CRANE:-
Sun Cartridge Use shore crane hold
stbd crane luffing
boom, removed counter
balance cartridge
found cotton rags
blocked cartridge port
2
and internal valve
spool jammed.
Yard overhaul cylinder
earlier.
Renewed cartridge and
serviced complete
cartridge block,
installed back in
position and function
tested satisfactory.
Page 1 of 4
Authorised HANLA IMS and since 1981 and over 8000 Track Recordsfor Deck Machinery, Steering
Gears, Valve Remote Controls.
SERVICE
raycOntrol pte ltd
7 TOH GUAN ROAD EAST #05-07 SINGAPORE
REPORT
608599Tel:65630544 Fax:65600941
Company Reg No : 198602637N
sales@raycontrol.com
JOBNO : 20120117
ISO 9001:2008 accredited
Page 2 of 4
LEAKAGE RECTIFIED:-
3
Stbd crane hoist motor
corroded removed and
leakage rectified.
4
RENEW TEST POINTNIPPLE & EXTENTION CONNECTOR:-
Both port and stbd crane renew all pressure test nipple and control block
extension hose connector.
Page 2 of 4
Authorised HANLA IMS and since 1981 and over 8000 Track Recordsfor Deck Machinery, Steering
Gears, Valve Remote Controls.
SERVICE
raycOntrol pte ltd
7 TOH GUAN ROAD EAST #05-07 SINGAPORE
REPORT
608599Tel:65630544 Fax:65600941
Company Reg No : 198602637N
sales@raycontrol.com
JOBNO : 20120117
ISO 9001:2008 accredited
Page 3 of 4
RETURN LINE FILTER:-
5
Both hose crane return
line filters renewed.
SLEWING MOTOR:-
Port slewing motor
counter balance valve
cartridge found
6
leaking. Temporary use
plastic steel/devcon
to prevent leakage.
Recommended renew
slewing counter
balance cartridge.
Page 3 of 4
Authorised HANLA IMS and since 1981 and over 8000 Track Recordsfor Deck Machinery, Steering
Gears, Valve Remote Controls.
SERVICE
raycOntrol pte ltd
7 TOH GUAN ROAD EAST #05-07 SINGAPORE
REPORT
608599Tel:65630544 Fax:65600941
Company Reg No : 198602637N
sales@raycontrol.com
JOBNO : 20120117
ISO 9001:2008 accredited
Page 4 of 4
CONTROL BLOCK
DANFOSS PVG 120:-
Port crane control
7
block
hoist spool
operating cover and
handle renewed.
LOAD TEST:-
Both port and stbd
8
hose crane load tested
with 18.5 ton as
satisfactory by
surveyor.
Report by :-Hasan
Service engineer
